Send Inquiryebmpapst 6314 N/2TDHPU Axial Fan 24V-3.5A 84W DC Brushless Air Cooling Fan 7200 RPM 172 * 172 * 51mm 4-Wire (Metal)
ebmpapst 6314 N/2TDHPU Axial Fan 24V-3.5A 84W DC Brushless Air Cooling Fan 7200 RPM 172 * 172 * 51mm 4-Wire (Metal) Specification
- Installation Guideline
- Panel mount, M4 screws (not included), 4-point mounting
- Humidity
- 595% RH (non-condensing)
- Material
- METAL
- Finish
- Anodized/painted metal
- Mounting Type
- Panel Mount
- Standard
- Conforms to EN 61000-6-3, UL, CE
- Thickness
- 51 mm
- Input Voltage
- 24 V DC
- Temperature
- -20C to +70C
- Process
- Die-cast housing, injection molded impeller
- IP Rating
- IP54
- Technique
- Brushless EC motor, ball bearing System
- Dimension (L*W*H)
- 172 Millimeter (mm)
- Application
- Electronic equipment cooling, industrial control panels, server racks
- Design
- 4-Wire PWM Speed Control
- Frequency
- Not Applicable (DC Motor)
- Equipment Type
- DC Brushless Axial Fan
- Weight
- Approximately 1.1 kg
- Product Type
- Axial Fan
- Color
- BLACK
- Service Period
- Continuous duty, >50,000 hours at 40C
- Tolerance
- Standard industrial tolerance
- Size
- 172mm
- Supply Voltage
- 24 V DC
- Processing
- Precision metal frame with brushless motor assembly
- Usage
- Air Cooling
- Surface Treatment
- Corrosion resistant painted finish
- Power Consumption
- 84 W
- Impeller Material
- Glass-filled polyamide
- Maximum Air Flow
- approx. 500 CFM (cubic feet per minute)
- Frame Material
- Aluminium
- Noise Level
- Approx. 65 dBA
- Bearing Type
- Ball Bearing
- Model Number
- 6314 N/2TDHPU
- Speed
- 7200 RPM
- Terminal Type
- 4-Wire (PWM + Tach)
- Lead Length
- approximately 300 mm
- Control Function
- Speed control via PWM, Tachometer output
- Motor Type
- EC brushless, electronically commutated
- Maximum Current
- 3.5 A
ebmpapst 6314 N/2TDHPU Axial Fan 24V-3.5A 84W DC Brushless Air Cooling Fan 7200 RPM 172 * 172 * 51mm 4-Wire (Metal) Trade Information
- Delivery Time
- 7 Days
About ebmpapst 6314 N/2TDHPU Axial Fan 24V-3.5A 84W DC Brushless Air Cooling Fan 7200 RPM 172 * 172 * 51mm 4-Wire (Metal)
Model: 6314 N/2TDHPU Voltage: 24V DC Current: 3.5A Power: 84W Speed: 7200 RPM Dimensions: 172mm x 172mm x 51mm Connection: 4-Wire (PWM control and tachometer output) Type: DC Brushless Axial Fan Material: Metal framePrecision Airflow and Reliable Cooling
Equipped to deliver high airflow of approximately 500 CFM, the ebmpapst 6314 N/2TDHPU ensures efficient heat dissipation in electronic enclosures and industrial equipment. Its corrosion-resistant painted finish and aluminium housing provide extra durability. The fan meets standards such as EN 61000-6-3, UL, and CE, promising both performance and safety.
Advanced Speed Control and Monitoring
The 4-wire configuration enables real-time PWM speed control and tachometer monitoring, allowing users to fine-tune operation for optimal efficiency or quietness. This flexibility supports environmental conditions ranging from -20C to +70C and 595% RH, making it suitable for various industrial and electronic cooling scenarios.
FAQs of ebmpapst 6314 N/2TDHPU Axial Fan 24V-3.5A 84W DC Brushless Air Cooling Fan 7200 RPM 172 * 172 * 51mm 4-Wire (Metal):
Q: How is the ebmpapst 6314 N/2TDHPU axial fan installed?
A: This fan is designed for panel mounting using four M4 screws (not included). It features a 4-point mounting pattern for secure and stable installation in electronic equipment, industrial control panels, or server racks.Q: What are the primary benefits of using this DC brushless axial fan?
A: It offers high airflow (up to 500 CFM), long operational life (>50,000 hours at 40C), precise speed control via PWM, and reliable monitoring with tachometer output. Its durable construction ensures continuous duty in demanding environments, reducing maintenance requirements.Q: When should I consider using the 6314 N/2TDHPU fan in my system?
A: Use this fan when you require efficient and reliable cooling for sensitive electronics, industrial automation systems, data center equipment, or environments where managing high heat loads is critical.Q: What process is involved in the manufacture of this fan?
A: The fan features a die-cast aluminium housing, injection molded glass-filled polyamide impeller, and a precision-assembled brushless EC motor with ball bearings. This high-quality construction delivers durability and consistent performance.Q: Where can this axial fan be effectively applied?
A: It is ideal for cooling electronics, server racks, control panels, and industrial automation equipment in environments like manufacturing facilities, data centers, and other high-density applications.Q: How does the fan provide speed control and monitoring?
A: Thanks to its 4-wire configuration, the fan supports PWM for adjustable speed control and a tachometer output for real-time speed feedback, allowing seamless integration into automated control systems.
