Delta 7CM 7015 AFB0712VHB 4-Wire PWM CPU Automatic Temperature Control Plastic Electric Industrial Fan

Name: Delta 7CM 7015 AFB0712VHB 4-Wire PWM CPU Automatic Temperature Control Plastic Electric Industrial Fan
Brand: G3R ENTERPRISES
Price: 1499.0 INR
Availability: InStock

Price 1499.0 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Delta 7CM 7015 AFB0712VHB 4-Wire PWM CPU Automatic Temperature Control Plastic Electric Industrial Fan Specification

Tolerance
0.3mm

Mounting Type
4-Hole Corner

Technique
High-Speed Molding

Standard
CE, RoHS

IP Rating
IP42

Service Period
50,000 hours (MTBF at 40C)

Supply Voltage
12V DC

Installation Guideline
Standard Screw Mounting

Material
High-Quality Plastic

Product Type
Industrial Cooling Fan

Size
70mm x 70mm

Surface Treatment
Smooth

Weight
45g

Process
Precision Engineering

Output Voltage
12V DC

Humidity
Operating: 5%~90% RH (non-condensing)

Design
Square Frame, 7 Blades

Dimension (L*W*H)
70mm x 70mm x 15mm

Frequency
Auto Variable via PWM

Temperature
Operating: -10C to +70C

Thickness
15mm

Application
Automatic Temperature Control Systems, Electronic Device Cooling

Finish
Matte

Equipment Type
4-Wire PWM Fan

Usage
CPU Cooling, Server, Set-top Box, Industrial Automation

Input Voltage
12V DC

Color
Black

Processing
Injection Molded

PWM Speed Control
Yes (Automatic Temperature Control)

Rated Current
0.38A

Reverse Polarity Protection
Yes

Noise Level
Up to 44 dBA

Max Speed
~6000 RPM

Power Consumption
4.56W maximum

Bearing Type
Ball Bearing

Connector Type
4-Pin PWM

Max Air Flow
45.82 CFM

Fan Model
AFB0712VHB

Blade Material
Composite Plastic (PBT+Fiberglass)

Delta 7CM 7015 AFB0712VHB 4-Wire PWM CPU Automatic Temperature Control Plastic Electric Industrial Fan Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
500 Pieces Per Month

Delivery Time
7 Days

About Delta 7CM 7015 AFB0712VHB 4-Wire PWM CPU Automatic Temperature Control Plastic Electric Industrial Fan

Experience superb cooling efficiency with the Delta 7CM 7015 AFB0712VHB 4-Wire PWM CPU Automatic Temperature Control Plastic Electric Industrial Fan, laureate in customizable airflow and top reliability. This triumphant fan offers high-speed precision engineering, powered by a 12V DC supply for steady performance across applications such as CPU cooling, industrial automation, and electronic device cooling. Featuring automatic PWM speed control, reverse polarity protection, and a durable ball bearing design, it is easy to buy and install, ensuring optimal thermal management and a service life of 50,000 hours.

Versatile Applications and Usage

Delta 7CM 7015 AFB0712VHB excels in a range of environments such as CPUs, servers, set-top boxes, and industrial automation systems. Its usage type spans automatic temperature control and electronic device cooling. The fan's application sites include facilities demanding controlled airflow and precise temperature maintenance, promising consistent and efficient performance for professional and industrial needs.

FOB Port, Certification, and Sample Policies

Goods are reliably shipped from leading ports like Chennai or Mumbai, ensuring timely shipment and consistent rate policies for bulk and single orders. The fan carries triumphant CE and RoHS certifications, reflecting superb manufacturing standards. Sample policies allow select evaluation before bulk orders, letting you verify the laureate quality and operational standards firsthand.

FAQ's of Delta 7CM 7015 AFB0712VHB 4-Wire PWM CPU Automatic Temperature Control Plastic Electric Industrial Fan:

Q: How does the Delta 7CM 7015 AFB0712VHB fan manage temperature control?

A: The fan features a 4-wire PWM connector for automatic temperature-based speed adjustments, helping maintain optimal device conditions.

Q: What are the primary applications for this industrial fan?

A: It is primarily used in CPUs, servers, set-top boxes, industrial automation, and other electronic device cooling systems requiring precise thermal management.

Q: Where can I use the Delta AFB0712VHB fan for best results?

A: Best results are achieved in settings that require stable, automated airflow, such as data centers, industrial machines, and high-performance electronic devices.

Q: What process was used in manufacturing this fan?

A: The fan is crafted using injection molding and precision engineering to ensure a dimensional tolerance of 0.3mm and high reliability.

Q: When should the fan be replaced or serviced?

A: Designed for endurance, it offers a service period of around 50,000 hours at 40C but should be replaced if efficiency drops or if noise exceeds typical levels.
